[hopfenundmalz]

I just have plastic 60L Spiedels at this point, but have considered a conical, as I like the concept of transferring clear wort under pressure.  I have always wondered how you clean and sanitize the dump valve in place after the dump of an early trub and unwanted yeast?  Just spray it down with StarSan?

That is what I do.

[yso191]

I just have plastic 60L Spiedels at this point, but have considered a conical, as I like the concept of transferring clear wort under pressure.  I have always wondered how you clean and sanitize the dump valve in place after the dump of an early trub and unwanted yeast?  Just spray it down with StarSan?

Do you mean clear wort or beer?  I ask because I can't think of a reason to transfer wort under pressure. Regardless either way is doable.  I have the Spiedel fermenter which I have used for several brews.  I transferred to the fermenter from the boil kettle (under pump pressure) coming out of the plate chiller.  When the fermentation is done I transfer under CO2 pressure to a keg.  If you a want picture of how I do it I can provide one.

[ynotbrusum]

I think either would work - wort or fermented beer - but I was meaning clear beer, really.  I would like to see your set up for pressurized transfer from the Speidel fermenter...I assume the screw on cap could be fitted with a cornie post and qcd?

[yso191]

Here is how I have done it:


The hose (I use silicone tubing) fits perfectly on the faucet output and the beverage-out ball-lock valve. I put hose clamps at both ends to seal it perfectly.   The yeast has always been just below the faucet, so not much gets into the keg.

Below is a picture of the top setup.  It is a #8 stopper held in place with the ring from an extra faucet I purchased.  The white T valve makes the final connection to the gas line.  2-3 psi from the CO2 canister and you're in business.



BTW, I use a #8 stopper with 2 holes in it for fermenting.  One has the airlock in it, the other a thermowell so I measure actual beer temperature.

[dkfick]

I bought a vacuum pump for transferring my meads awhile back.. so I've been doing the opposite and transferring my beers via vacuum.  Mostly because it's super easy.  Though I suppose I am taking co2 out of solution when I do it and I then have to use a slight bit more co2 to carb the beers back up.  Probably would use more co2 if I did the pressurized transfer still though... ;-)

[ynotbrusum]

Here is how I have done it:


The hose (I use silicone tubing) fits perfectly on the faucet output and the beverage-out ball-lock valve. I put hose clamps at both ends to seal it perfectly.   The yeast has always been just below the faucet, so not much gets into the keg.

Below is a picture of the top setup.  It is a #8 stopper held in place with the ring from an extra faucet I purchased.  The white T valve makes the final connection to the gas line.  2-3 psi from the CO2 canister and you're in business.



BTW, I use a #8 stopper with 2 holes in it for fermenting.  One has the airlock in it, the other a thermowell so I measure actual beer temperature.

Nice set up.  I have 60 liter models (2), so I will check this out (no screw top lid on mine - they are perimeter snap lock).  I won't have gravity on my side, either, since I will be going from a chest freezer up and out to a cornie, but it will beat heavy lifting of 10+ gallon batches.  How does your gas hose connect?  Just slip it over the barb?  Mine are barrel nuts on the end of my lines and I'd hate to remove them each time I rack.....

[yso191]

I am so illiterate with respect to metric conversion it didn't occur to me that you had one of the big boys.  So here's a thought.  When I was using carboys I used a two-hole stopper with a racking cane in one and CO2 pressure in the other.  Something similar may work for your setup.

[Stevie]

I've seen others that have used a second spigot on the top and hooked the CO2 directly up to that.

[gmac]

I am so illiterate with respect to metric conversion

5 US gals is about 19L.  For a 60 L vessel, you could say it's close enough to 15 US gals.

[yso191]

I am so illiterate with respect to metric conversion

5 US gals is about 19L.  For a 60 L vessel, you could say it's close enough to 15 US gals.

Yeah, I know.  I've seen that conversion countless times.  Its about memory... no probably importance to me.  I just don't care enough to remember it or take the time/effort to recall it.  It brings me no pleasure.  As a general rule I resist doing math in my head - always have.  When I went to college they put me in a remedial math class - then when I transferred 2 years later I had forgotten it all and after the entrance exam the second university put me back in remedial math to learn it all over again.  I actually went to a counselor once while in the second math class because I was always falling asleep while studying for the class.  Her response?  "Stand up while studying."

All the sudden I want to tell you that I also was class valedictorian and had a 4.0 GPA at the first college.  I guess I don't want you to think I'm just plain dumb.

[gmac]

I am so illiterate with respect to metric conversion

5 US gals is about 19L.  For a 60 L vessel, you could say it's close enough to 15 US gals.

Yeah, I know.  I've seen that conversion countless times.  Its about memory... no probably importance to me.  I just don't care enough to remember it or take the time/effort to recall it.  It brings me no pleasure.  As a general rule I resist doing math in my head - always have.  When I went to college they put me in a remedial math class - then when I transferred 2 years later I had forgotten it all and after the entrance exam the second university put me back in remedial math to learn it all over again.  I actually went to a counselor once while in the second math class because I was always falling asleep while studying for the class.  Her response?  "Stand up while studying."

All the sudden I want to tell you that I also was class valedictorian and had a 4.0 GPA at the first college.  I guess I don't want you to think I'm just plain dumb.

I'm with you.  I have a math phobia.  In university others seemed to look at a formula and things would become clear. To me, they just become more complex.  The reason I remember is because I buy distilled water in 15L jugs and I do 15 US gal batches so that I end up with 3 cornies.

[Stevie]

Quarts and liters are close enough in volume that I treat them the same in my head.

[ynotbrusum]

Quarts and liters are close enough in volume that I treat them the same in my head.

+1 that's easier.  With the 60 liter Speidel, I do just 10-13 gallon batches, mostly lagers.  Ales go in regular 6.5 gallon ale pails ...

Good ideas on the CO2 alternatives and we have officially hijacked this thread - sorry OP!

[hopfenundmalz]

Quarts and liters are close enough in volume that I treat them the same in my head.

They are close. ~3.8L=1 Gallon. I have read that a lot for some reason.

[gmac]

Quarts and liters are close enough in volume that I treat them the same in my head.

+1 that's easier.  With the 60 liter Speidel, I do just 10-13 gallon batches, mostly lagers.  Ales go in regular 6.5 gallon ale pails ...

Good ideas on the CO2 alternatives and we have officially hijacked this thread - sorry OP!

As the OP, I'm OK with the hijack

I got the answer (though not the one I wanted because I wanted to steal yeast to brew this weekend).
